MGX QFP 48-11 4-Up Panel


MGX QF 48-11 4-Up Panel
MGX QF 48-11 4-Up Panel

MGX QFP 48-11 4-Up Panel

Description

The MGX QFP 48-11 4-Up Panel test set is designed to test SMT Top Side, SMT Bottom Side and Selective Soldering processes. Quadrant 1 is designed to test the QFN components on the top side of the board. Quadrant 2 is designed to test the QFN components on the back side of the board. Quadrant 3 is designed to test the SMT connector and 0805 caps on the top side of the board. Quadrant 4 is designed to test the TH pins and 0805 caps on the bottom side of the board. This multifunctional test board is ideal for evaluating No-Clean and Cleaning processes.

In Stock • Ready for Shipment

Uses

Surface Mount Technology

Solder Paste Characterization

No-Clean Soldering

Rework

Selective Soldering

Manual Soldering

Double-Sided Mixed Technology

Cleaning (Top Side, Bottom Side, Topical)
